Multiqiuip

Mikasa MVC88 20" Forward Plate Compactor

Mikasa MVC88 20 Forward Plate Compactor

The new MVC88 now features a single cast baseplate and eccentric housing to enhance plate durability, serviceability and performance. An hour/tachometer to help measure runtime and engine rpm is now a standard feature. The plate is even easier to transport with the new wheel kit design. All this combined with an advanced anti-vibration handle make the MVC88 the newest and most technically advanced plate compactors on the market.

  • Reliable engine with Honda GX160 offering easy start-up and low oil shutdown for durability.
  • Cyclonic pre-cleaner captures most airborne contaminants for engine protection and extended service life.
  • Single cast baseplate and eccentric housing lowers center of gravity and increases travel speed by 12% for greater productivity.
  • Hour/tachometer measures runtime and engine rpm.
  • Tubular steel roll bar protects engine components and provides central lifting point.
  • Sealed belt cover keeps dirt and rocks out extending belt life.
  • Open base plate design makes for easier removal of dirt and rock build-up.
  • Cog-tooth belt drive enables longer life compared to conventional V-belts.
  • Optional urethane plate attachment for use on paving stones and brick pavers (UPA88T).
  • Optional transport wheel kit WHL88T for serial number T2A9197 and below.  WHL88TC for serial number T2A9198 and above.

Choose : No Water Tank / With Water Tank

Choose Model No Water Tank
Choose Model
Price Qty Purchase
Call For Price
Item ID MVC88VTH In Stock
Save to Wish List

Additional information

Weight
Dimensions

Reviews

not yet rated
not yet rated
0 reviews

Your review

Description

Unit Specifications
Centrifugal Force 3372 lbf 15 kN
Exciter Speed 6000 VPM
Plate Size 19.7 x 20.7 in
500 x 525 mm
Max Forward Speed
Per Min.
82 ft 25 m
Fuel Consumption
Per Hour
0.31 gal 1.17 L
Dimensions & Weights
Overall Length 41.75 in 1060 mm
Overall Width 19.75 in 502 mm
Overall Height 37 in 940 mm
Shipping Dimensions 38 x 22 x 29 in
965 x 559 x 737 mm
Operating Weight 207 lb 94 kg
Shipping Weight 225 lb 102 kg
